ELECTRONIC POCKET SCALE

Source:Jiangyin SuoFei Electronic Technology Co.,Ltd. Release time:2022-06-17 17:24:19 Author:865

1. Specification


Power supply: 2 x AAA battery
Unit: g oz ozt dwt gn ct T

1. Operation:
Insert 2xAAA battery into battery compartment.
Place the scale on a flat and stable surface.
Press button to turn the scale on.
Wait until the display shows “0.00” (zero) before placing any weight on the scale.
Carefully place the item(s) to be weighed onto the weighing platform
After a few seconds, the weight should stablize and you can now get the weight reading from the LCD display.
Using “UNIT “ button you can switch between weighing units( g oz ozt dwt gn ct T)
Using “TARE” button you can reset the display to zero when weight is on the scale, allowing you to subtract the weight of a container.
Using “PCS” button to count quantity. When the scale is open, long press PCS button, press UNIT button to choose sample quantity(25/50/75/100), put items according to the sample quantity you choose, press PCS button to confirm, put all items that you want count, the display will show quantity. If all items are overload, the display will show “O-LD”

1. Calibration:
Turn on the scale
Long press “Unit” button until “CAL” appears
It will then flash one calibration value
Put standard weight on the scale according to what displat shows.
It will then flash another calibration value
Put standard weight on the scale according to what displat shows.
It will then flash “PASS”
Now the scale is calibrated


Attention

  • Never load the scale with more than the maximal capacity. Overloading can permanently damage it!
  • Avoiding any exposure to extreme heat or cold, your scale works better when operated at normal room temperature. Always allow the scale to acclimate to normal room temperature for at least 1 hour before use.
  • Keep your scale in a clean environment. Dust, dirt, moisture, vibration, air currents and a close distance to other electronic equipment can all cause an adverse effect on the reliability and accuracy for your scale.
  • Handle with care. Although this scale is designed to be quite durable, try to avoid rough treatment as this may permanently damage the internal sensor.
  • Avoid shaking, dropping the scale. This is precision instrument and must be handled with extreme care. Only operate the scale on a stable, vibration free surface.
